Autonics
Features
- Shaft outer diameter : Ø4mm
- Max. response frequency : 300kHz
- Max. allowable revolution : 5000rpm
- Starting torque : Max. 20gf.cm(max. 0.00196N.m)
- Resolution : 200P/R
- Control output : NPN open collector
- Power supply : 12-24VDC
±5%(ripple P-P: max. 5%) - Connection type : Axial cable type
- Protection structure : IP50
Specifications
Data sheet
| Shaft outer diameter | Ø4mm |
|---|---|
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 20gf.cm(max. 0.00196N.m) |
| Resolution | 200P/R |
| Output phase | A, B, Z |
| Control output | NPN open collector |
| Power supply | 12-24VDC ±5%(ripple P-P: max. 5%) |
| Connection type | Axial cable type |
| Protection structure | IP50 |
| Approval |  |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Ø4mm coupling |
| Weight | Approx. 80g |
