$ 62.33
SICK sensor one of the world’s leading producers of sensors and sensor solutions for industrial applications. SICK is a technology and market leader in Factory and Logistics Automation as well as Process Automation. The sensor range are: Laser Sensors, Cylinder Sensors, Photoelectric Sensors, Fork Sensors, Encoders, Color Sensors, Distance Sensor, Contrast Sensor, Color Sensor, Inductive Proximity Sensors, Fiber Optic Sensor with our signature range sick sensor intelligence.
Part Number:1058194
Photoelectric Sensor Model: GRTE18S-N1317
OEM Spec Ref
| Sensor/ detection principle | Photoelectric proximity sensor, Energetic | ||||||||||||
| Dimensions (W x H x D) | 18 mm x 18 mm x 38.1 mm | ||||||||||||
| Housing design (light emission) | Cylindrical | ||||||||||||
| Thread diameter (housing) | M18 x 1 | ||||||||||||
| Optical axis | Axial | ||||||||||||
| Sensing range max. | 3 mm … 115 mm 1) | ||||||||||||
| Sensing range | 5 mm … 100 mm 1) | ||||||||||||
| Type of light | Visible red light | ||||||||||||
| Light source | PinPoint LED 2) | ||||||||||||
| Light spot size (distance) | Ø 8 mm (100 mm) | ||||||||||||
| Wave length | 650 nm | ||||||||||||
| Adjustment | Potentiometer, 270° | ||||||||||||
|
|||||||||||||
| Supply voltage | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 30 mA |
| Switching output | NPN |
| Switching mode | Light switching |
| Signal voltage NPN HIGH/LOW | Approx. VS / ≤ 3 V |
| Output current Imax. | ≤ 100 mA 3) |
| Response time | < 1,000 µs 4) |
| Switching frequency | 500 Hz 5) |
| Connection type | Cable, 3-wire, 2 m 6) |
| Cable material | PVC |
| Circuit protection | A 7)
B 8) D 9) |
| Protection class | III |
| Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Items supplied | Fastening nuts (2 x) |
| Electromagnetic compatibility (EMC) | EN 60947-5-2 |
| Ambient operating temperature | –25 °C … +55 °C 10) |
| Ambient temperature, storage | –40 °C … +70 °C |
| UL File No. | NRKH.E348498 & NRKH7.E348498 |
