$ 605.36
GigE, CMOS, 76.0 fps, 1456 x 1088, 1.58 MPix, 1/3″, Sony, Global Shutter
(GigE Vision)
Product:
GV-5040CP-C-HQ (colour)
GV-5040CP-M-GL (monochrome)
(Illustrations may differ from the original)
IDS industrial camera or machine vision cameras was the most easy integration cameras in the market. Therefore is so easy for IDS cameras become most compatible with market most popular machine vision software such as OpenCV, Labview, Cognex and Halcon vision software. IDS also provide wide range of industrial C-mount cameras such GigE, 5 GigE, 10 GigE, USB 2.0, USB 3.0, and USB 3.1 interfacing models.
Meanwhile, if you need technical support please email us sales@inosaki.com
The GV-5040CP is equipped with Sony’s Global-Shutter CMOS sensor IMX273 from the Pregius series and offers a resolution of 1.58 MPix (1456 x 1088 pixels) at 3.45 µm pixel size. At full resolution, the sensor accelerates up to 76.0 fps and provides excellent image quality even with moving vision systems as well as in low light scenarios. This makes it ideal for machine vision applications such as surface inspection, detailed image analysis in medical technology or for use in traffic applications.
This camera model will be supported beginning with IDS Vision Firmware 1.5.
| Item number |
|
|---|---|
| Name | GV-5040CP |
| Family | CP |
| Interface | GigE |
| Sensor type | CMOS |
| Manufacturer | Sony |
| Frame rate | 76.0 fps |
| Resolution (h x v) | 1456 x 1088 |
| Optical Area | 4.996 mm x 3.747 mm |
| Shutter | Global Shutter |
| Optical class | 1/3″ |
| Resolution | 1.58 MPix |
| Pixel size | 3.45 µm |
| IP code | IP30 |
| Data sheet |
| Weight | N/A |
|---|---|
| Dimensions | N/A |
