$ 34.50
PEPPERL+FUCHS Inductive proximity sensors are the preferred choice for the majority of applications requiring accurate, non-contact detection of metallic objects in machinery or automation equipment. As a pioneer and market leader, Pepperl+Fuchs offers innovative, high quality inductive sensors to meet the needs of the worldwide automation and process control markets. Our experience, flexibility and customer focus continues to allow us to offer custom designed solutions for the most unique and demanding applications.
| General specifications | ||
|---|---|---|
| Switching function | Normally open (NO) | |
| Output type | Two-wire | |
| Rated operating distance | 3 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Assured operating distance | 0 … 2.4 mm | |
| Actual operating distance | 2.7 … 3.3 mm typ. | |
| Reduction factor rAl | 0.45 | |
| Reduction factor rCu | 0.35 | |
| Reduction factor r304 | 0.8 | |
| Reduction factor rBrass | 0.5 | |
| Output type | 2-wire | |
| Nominal ratings | ||
| Operating voltage | 5 … 60 V DC | |
| Switching frequency | 0 … 2000 Hz | |
| Hysteresis | typ. 0.2 mm | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | no | |
| Inductive overvoltage protection | yes | |
| Voltage drop | ≤ 4 V | |
| Voltage drop at IL | ||
| Voltage drop IL = 10 mA, switching element on | 3.4 … 3.9 V typ. 3.6 V | |
| Operating current | 4 … 100 mA | |
| Lowest operating current | 4 mA | |
| Off-state current | 0.4 … 0.55 mA typ. 0.46 mA | |
| Time delay before availability | ≤ 1 ms | |
| Switching state indicator | LED, yellow | |
| Limit data | ||
| Tightening torque, fastening screws | 0.4 Nm | |
| Functional safety related parameters | ||
| MTTFd | 1552 a | |
| Mission Time (TM) | 20 a | |
| Diagnostic Coverage (DC) | 0 % | |
| Compliance with standards and directives | ||
| Standard conformity | ||
| Standards | EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 |
|
| Approvals and certificates | ||
| UL approval | cULus Listed, General Purpose | |
| CSA approval | cCSAus Listed, General Purpose | |
| CCC approval | Certified by China Compulsory Certification (CCC) | |
| Ambient conditions | ||
| Ambient temperature | -25 … 85 °C (-13 … 185 °F) | |
| Mechanical specifications | ||
| Connection type | cable PVC , 130 mm | |
| Core cross section | 0.14 mm2 | |
| Housing material | PBT | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
| Cable | ||
| Cable diameter | 3 mm ± 0.2 mm | |
| Bending radius | > 10 x cable diameter | |
| Mass | 7.5 g | |
| Weight | 0.0075 kg |
|---|
