$ 80.04
| suitability for use | for connecting PROFIBUS stations to the PROFIBUS bus cable |
| transfer rate | |
| transfer rate / with PROFIBUS DP | 9.6 kbit/s … 12 Mbit/s |
| interfaces | |
| number of electrical connections | |
| ● for PROFIBUS cables | 2 |
| ● for network components or terminal equipment | 1 |
| type of electrical connection | |
| ● for PROFIBUS cables | Integrated insulation displacement terminals for 2-core PB FC installation cables |
| ● for network components or terminal equipment | 9-pin sub D connector |
| type of electrical connection / FastConnect | Yes |
| mechanical data | |
| design of terminating resistor | Resistor combination integrated and connectable via slide switch |
| material / of the enclosure | plastic |
| locking mechanism design | Screwed joint |
| design, dimensions and weights | |
| type of cable outlet | 90 degree cable outlet |
| width | 15.8 mm |
| height | 59 mm |
| depth | 35.6 mm |
| net weight | 36 g |
| ambient conditions | |
| ambient temperature | |
| ● during operation | -25 … +60 °C |
| ● during storage | -40 … +70 °C |
| ● during transport | -40 … +70 °C |
| protection class IP | IP20 |
| product features, product functions, product components / general | |
| product feature | |
| ● silicon-free | Yes |
| product component | |
| ● PG connection socket | No |
| ● strain relief | Yes |
| standards, specifications, approvals | |
| certificate of suitability | |
| ● RoHS conformity | Yes |
| ● UL approval | Yes |
| reference code | |
| ● according to IEC 81346-2 | XG |
| ● according to IEC 81346-2:2019 | XGA |
| Weight | 0.040 kg |
|---|---|
| Dimensions | 6.8 × 7.7 × 3.2 cm |
